微源芯片 LP3984-30B5F 低衰減LDO穩(wěn)壓器

Absolute Maximum Ratings

◆ Supply Input Voltage: 6.5V

◆ Other Pin Voltage: -0.3V to VN+0.3V

Power Dissipation, Po @TA=25℃

◆ SOT23-5: 500mW

Package Themal Resistance

◆ Themmal Resistance (SOT23-5) (a): 195℃W

◆ Themal Resistance (SOT23-5) (Uc): 60℃/W

◆ Maximum Junction Temperature: 150℃

◆ Maximum Soldering Temperature (at leads, 10 sec): 260℃

◆ Storage Temperature Range: -65℃ to 150℃

ESD Susceptility

◆ HBM (Human Body Mode): 2kV

◆ MM (Machine-Mode): 200V

Recommended Operating Conditions

◆ Supply Input Voltage: 2.5V to 5.5V

◆ EN Input Voltage: 0V toVw+0.3V

◆ Operation Junction Temperature Range:  -40℃ to 125℃

◆ Operation Ambient Temperature Range: -40℃ to 85℃

Applications

◆ Portable Media Players/MP3 players

◆ Cellular and Smart mobile phone

◆ LCD

◆ DSC Sensor

◆ Wireless Card
