微源 LP3986B3F 600mA超低噪聲LDO穩(wěn)壓器

General Description

The LP3986HX3F is designed for portable applications with demanding performance and space requirements. The LP3986 performance is optimized for battery-powered systems to deliver ultra low noise and low quiescent current. Regulator ground current increases only slightly in dropout, further prolonging the battery life.

The LP3986 also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio.

Features

◆ Ultra-Low-Noise for RF Application

◆ 2.5V- 6V Input Voltage Range

◆ Low Dropout : 220mV @ 300mA

◆ Ultra-Fast Response in Line/Load Transient

◆ Current Limiting and Thermal Shutdown Protection

Application

◆ PMP/PDA/MP3 players

◆ Cellular and Mobile phone

◆ RF Module

◆ Sensor Module
