| 型號： | G1582T11U |
| 廠 商： | 臺灣 |
| 品牌/商標: | 臺灣致新（GMT） |
| 產(chǎn)品類別： | 集成電路/IC- 充電管理芯片 |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
臺灣致新+科瑞芯電子供應G1582T11U，GMT原廠原裝
G1582特點：
Wide Supply Operation Range +4.5V to +20V
Input Common Voltage Range Beyond the Rails
Rail-to-Rail Output Voltage Swing
High Peak Source Capability 1300mA
High Peak Sink Capability 850mA
Low Input Offset Voltage 3mV (Typical)
Wide -3dB Bandwidth 35MHz
Quiescent Current: 2.2mA
Large DC Voltage Gain 80dB (Typical)
Slew-Rate 50V/μs
Unit-Gain Stable
產(chǎn)品應用：
Portable Equipment
LCD-TV Equipment
Battery-Powered Equipment
ASIC Input or Output Amplifier
Low Power/Low Voltage Applications
