General Description

The G9091 is a low supply current, low dropout linear regulator that comes in a space saving SOT-23-5 package. The supply current at no-load is 100μA. In the shutdown mode, the maximum supply current is less than 1μA.

The over-current protection limit is set at 430mA typical. An overtemperature protection circuit is built-in in the G9091 to prevent thermal overload. These power saving features make the G9091 ideal for use in the battery-powered applications such as notebook computers, cellular phones, and PDA’s.

These devices feature a shutdown function and are offered in active low with auto discharge. The G9091 is specifically designed to employ ceramic output capacitors.

Applications

■ Notebook Computers

■ Cellular Phones

■ PDAs

■ Digital still Camera and Video Recorders

■ Hand-Held Devices

■ Bar Code Scanners
