深圳供應 G509L10DT11G 致新電源開關芯片
Features
● 67mΩ High-Side MOSFET(G509xxxxT11G, G509x1SDTB1G)
● 120mΩ High-Side MOSFET(G509N02DT73G)
● 37mΩ High-Side MOSFET(G509x3xDxx1G)
● Available with 9 Versions of Current Limits with Fold-back.
● Operating Range:2.7V to 5.5V
● 2mS Typical Rise Time
● Fast Over Current Response 1.5μs (TYPICAL)
● Under Voltage Lockout
● 130μA Quiescent Supply Current
● 1μA Maximum Shutdown Supply Current
● Logic Level Enable Pin. Available with Active-High, Active-Low, or Enable Selection Versions
● No Reverse Current when Power Off
● Deglitched Open-Drain Over-Current Flag Output (OC )
● Available with or without Output Shutdown Pull-low Resistor
● Output Reverse Protection when Power ON
● G509xxxxT11G SOT-23-5 Package
● G509x25DTB1G SOT-23-6 Package
● G509N02DT73G SOT-23-3 Package
● G509x30DTO1G TSOT-23-5 Package
● G509xxxDTP1G TSOT-23-6 Package
● G509xxxDTR1G SOT-563 Package
● UL 2367 Recognition-File NO. E232223
● IEC 62368-1 Certified
Applications
● High-Side Power Protection Switch
● USB Power Management
● USB Host and Self-Powered Hubs
● USB Bus-Powered Hubs
● Hot Plug-In Power Supplies
● Battery-Charger Circuits
