產品詳情

                臺灣威盛（VIA）電池充電支持的USB電源開關方案VP201

產品型號：VP201

封裝：DFN-8

包裝：3000pcs/盤（拆盤需申請）

產品應用：通用墻壁充電適配器、外部備用電池、汽車點煙器充電器、充電站等... ...

產品特點：

● 95mΩ(Typ.) MOSFET Power Switch

● Compatible with USB 2.0 and 3.0 power switch requirement

● Supports charging for most available Apple devices, BC 1.2 compliant devices and Samsung Devices

● Meets Chinese Telecommunication Industrial Standard YD/T 1591-2009

● Meets Battery Charging Specification BC 1.2 for DCP

● Automatic selection of D+/D- mode for an attached device

● Adjustable current limit up to 2.6A (Typ.)

● Thermal and Short-Circuit protection

● Under-Voltage Lock Out protection

● OUT node discharge support

● Reverse current blocking

● Ambient operating temperature: -20C to 85C

● Available in 8-pin ESOP package

● Lead(Pb)-Free and RoHS compliant
