| 型號： | ETA5060V285D2I |
| 廠 商： | 中國 |
| 品牌/商標: | ETA |
| 產品類別： | 鈺泰/ETA- |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
ETA5060V285D2I 電子元器件 ETA鈺泰 封裝DFN2x2-8
1A，低智商，高精度，快速瞬態低降壓穩壓器
1A, Low IQ, High Accuracy, Fast Transient Low Dropout Voltage Regulator
ETA5060 is a low dropout (LDO) voltage regulator capable of sourcing 1A with only 140mV of dropout. ETA5060 output is adjustable with external resistors from 0.8V to 5V. ETA5060 wide input-voltage range supports operation as low as 1.8V and up to 5.5 V.
Features
Programmable Output Voltage Configuration
High Accuracy Output Voltage: ±2%
Wide Input Voltage Range: 1.8V to 5.5V
Wide Output Voltage Range: 0.8V to 5V
Low Power Consumption: 20μA Quiescent Current
Low Dropout: 140mV at 1A
Fast Transient Response
Stable with Small 1μF Capacitor
Inrush Current Protection
Available in SOT89-5, HFBP1.2×1.6-8, DFN1.2×1.6-8, DFN2x2-6, and DFN2x2-8
