SCT2460FRAR 芯洲科技6A同步降壓轉(zhuǎn)化器
FEATURES
● Wide Input Range: 3.8V-36V
● Up to 6A Continuous Output Current
● 0.8V ±1% Feedback Reference Voltage
● Integrated 36mΩ High-Side and 13mΩ Low-Side Power MOSFETs
● Pulse Skipping Mode (PSM) with 25uA Quiescent Current in Sleep Mode
● 100ns Minimum On-time
● Adjustable Soft-start Time
● Adjustable Frequency 100KHz to 2.2MHz
● External Clock Synchronization
● Frequency Spread Spectrum (FSS) Modulation for EMI Reduction
● Precision Enable Threshold for Programmable Input Voltage Under-Voltage Lock Out Protection (UVLO) Threshold and Hysteresis
● Low Dropout Mode Operation
● Over-voltage and Over-Temperature Protection
● Available in 3mmx4mm QFN-10L Package
APPLICATIONS
● Battery Pack Powered System - Cordless Power Tools, Cordless Home Appliance, Drone, Aero Modeling, GPS Tracker etc.
● Cigarette Lighter Adapters, Chargers
● USB Type-C Power Delivery, USB Charging
● Industrial and Medical Distributed Power Supplies
● Optical Communication and Networking System
● Automotive System
