| 型號： | LP3992-30B5F |
| 廠 商： | |
| 品牌/商標: | 微源半導體 |
| 產品類別： | 集成電路/IC- DC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
微源代理商熱推 LP3992-30B5F LDO穩壓器芯片
General description
The LP3992-15B5F is designed for portable RF and wireless applications with demanding performance and space requirements. The LP3992 performance is optimized for battery-powered systems to deliver ultra low noise and low quiescent current.
The LP3992 also works with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications, critical in hand-held wireless devices.
The LP3992 consumes less than 0.1μA in shutdown mode and has fast turn-on time less than 50μs. The other features include ultra low dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio. It is available in the 5-lead of SOT23-5 and TSOT23-5 packages.
Applications
◆ Portable Media Players/MP3 players
◆ Cellular and Smart mobile phone
◆ LCD
◆ DSC Sensor
◆ Wireless Card
