| 型號： | ZPCT2P5M471L |
| 廠 商： | |
| 品牌/商標: | ZOWIE/智威 |
| 產品類別： | ZOWIE- 肖特基二極管 |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
SPECIFICATIONS
* Nominal Capacitance: 470μF
* Rated Voltage: 2.5V
* Capacitance Tolerance: Y= -35% ~ +10%
* Operating Temperature Range: -55 ~ +105C
* Capacitance Range: 214.5μF~363μF +20℃, 120Hz
* Leakage Current (L .C.): 82.5μA (max.) +20℃, after 2 minutes
* Dissipation Factor (Tan 8): 0.06 (max.) +20C, 120Hz
* Equivalent Series Resistance: 9mΩ (max.)+20C, 100kHz
* Surge Voltage: 1.25 x rated working voltage
* Damp Heat, Steady State
Capacitance change: +70% 1 -20% of initial measured value
Dissipation factor (Tan δ):≦ 2 times of the initial limit
Leakage Current (L.C.):Within the initial specified value
* Endurance
Capacitance change: +20% of initial measured value
Dissipation factor (Tan δ): 150% of initial specifed value
Leakage Current (L.C.): Initial specified value
