| 型號： | PT6108 |
| 廠 商： | |
| 品牌/商標: | PCT/普誠 |
| 產(chǎn)品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
普誠驅動器 PT6108 采用COG封裝
DESCRIPTION
The PT6108 is a CMOS silicon source driver IC foractive matrix TFT LCD panels. After a CMOS/RSDS 6-bit RGB data is applied, this device will generate 64-gray scale for driving the TFT LCD panel sourcelines. It supports 1200/1050/1026/1020/960 channel selectable function,shift right/left selectable function, and cascade functionfor dot expansion.
FEATURES
● 64-gray scale source driver for active matrix TFTLCD panels
● Selectable 1200/1050/1026/1020/960 output channels
● Logic voltage power supply: 2.3V to 3.6V
● High voltage power supply: 6.5V to 13.5V
● Maximum RSDS operating frequency at 90MHz
● Bi-directional shift right/left function
● COG package
