| 型號： | PT12469 |
| 廠 商： | |
| 品牌/商標: | PCT/普誠 |
| 產(chǎn)品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
雙H橋電機驅(qū)動器 PT12469 普誠原裝現(xiàn)貨
FEATURES
● Automotive AEC-Q100 Grade 1 (-40C~+125C) Qualified
● 8.2V to 36V Supply Voltage Range
● 1.6-A Maximum Driving Current at VM=24V (with additional heatsink)
● EN-PH Control Logic Interface
● Dual H-Bridge Driver with 4 Level PWM Current Control
● Winding Current Decay Modes
- Mixed Decay
- Slow Decay
- Fast Decay
● Drives Single Bipolar Stepping Motor or Dual DC Motors
● Built In a 3.3V Reference Voltage Output
● Low-Power Sleep Mode
● Protection Features
- Over Current Protection (OCP)
- Thermal Shutdown (TSD)
- VM Under Voltage Lock Out (UVLO)
- Fault Indication Pin (FAULTN)
APPLICATIONS
● Automatic teller machines
● Video security cameras
● Printers
● Scanners
● Office automation machines
● Amusement machines
● Factory automation
● Robotics
