| 型號： | PT5618 |
| 廠 商： | |
| 品牌/商標: | PCT/普誠 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
原廠原裝 PT5618 普誠200V三相柵極驅動器
FEATURES
● Integrated 200V half-bridge high side driver
● Driver up to 3-phase half-bridge gates
● Built-in deadtime control
● Shot-through protection
● Under voltage lockout for VCC and VBS
● 3.3V, 5V,15V input logic Compatible
● Built-in input filter
● Low standby current
● IO+/IO-: 320mA/620mA
● Builtin dead time: 0.55μs(typ.)
● Common-Mode dv/dt Noise Canceling Circuit
● Tolerant to negative transient voltage
● Low di/dt gate drive for better noised immunity
● -40°C- 125°C operating range
● Small footprint package: TSSOP20P/24P,173mil
APPLICATIONS
● 3-phase Motor Driver for E-BIKE, electric power tool
● Mini/micro motor control powered by battery
● Home appliance fed by 110V-AC grid
● General purpose inverter
