深圳供應(yīng) PT2260 PCT普誠 遠程控制編碼器
DESCRIPTION
PT2260 is a remote control encoder paired with eitherPT2270 or PT2272 utilizing CMOS Technology. Itencodes data and address pins into a serial codedwaveform suitable for RF modulation. PT2260 has amaximum of 10 bits tri-state address pins providing upto 59,049 (or 310) address codes; thereby, drasticallyreducing any code collision and unauthorized codescanning possibilities.
PT2260 is one of the first generation ofEncoder/Decoder ICs that utilizes the unique PTCTechnology. When paired with PT2270, thisencoder/decoder (PT2260/PT2270) pair can operate atvery wide temperature range (see Features). Thus, thisvery important feature enables your Encoder/Decoderto operate under the worst environmental condition.
FEATURES
● High performance CMOS technology
● Low power consumption
● Very high noise immunity
● Wide operating temperature range: -40℃ ~ 85℃
● 8or 10 Tri-State code address pins
● 2or4datapins
● Wider range of operating voltage: 1.8 ~ 10.0V
● Single resistor oscillator
● Least external components
APPLICATIONS
● Home/Car security system
● Garage door controller
● Remote fan controller
● Remote control toys
