現貨供應 RS358 PCT普誠 低功耗雙運算放大器
DESCRIPTION
These devices consist of two independent, high gain,internally frequency-compensated operationalamplifiers designed operate from a single supply overa wide range of voltages. Operation from split suppliesalso is possible if the difference between the twosupplies is 3V to 32V, and Vcc is at least 1.5V morepositive than the input common-mode voltage, the lowsupply-current drain is independent of the magnitudeof the power supply voltage.
FEATURES
● Two intermally compensated OP amps
● Intemally frequency compensated for unity gain
● Short circuit protection
● Wide power supply range: 3Voc to 32Voc (Single supply)
● Input common-mode voltage range includes ground
● Large output voltage swing: 0Voc to Vcc-1.5Vc
APPLICATIONS
● Electronic products
● Power supply
● Remote controller
● Consuming products
