PCT普誠 PT2513B 三相無傳感器驅動器 原裝正品

DESCRIPTION

PT2513 is an integrated three-phase sensorless BLDC motor driver chip with advanced protection functions, including soft-start circuit, thermal shutdown, lock on protection and output current protection. PT2513 uses sine wave current control to reduce electromagnetic noise during operation, and is suitable for fan motor drives that require high efficiency. On the speed control interface, it supports PWM or VSP (DC) commands, so that the motor can be controlled smoothly from low speed to high speed.

PT2513 adopts the BCD process, only a single VDD power supply is needed for use, and only a few parts are needed around it. The chip is packaged as HTSSOP16, HTSSOP20 and QFN20 with bottom heat dissipation, which can achieve excellent energy efficiency, making it compact, low-cost, and Ideal solution for sensor BLDC motor drive.

FEATURES

● Three-phase sensorless driver IC

● 6V ~ 16V voltage operating range

● 180 degree sine wave current operation

● Soft start control function

● PWM or VSP (DC) input speed control

● Maximum and minimum duty cycle limit settings

● Lock on and over-temperature protection

● Current limit protection function

● FG or 1/2FG speed signal output

APPLICATIONS

● Three phase sensorless BLDC driver

● CPU,GPU, or server cooling fan

● Refrigerator fan
