| 型號： | G948C3330TA1U |
| 廠 商： | |
| 品牌/商標(biāo): | GMT/致新 |
| 產(chǎn)品類別： | GMT- |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
致新 G948C3330TA1U 低壓差線性穩(wěn)壓器 SOT-353封裝
General Description
The G948 is a low-supply current, low-dropout linear regulator. An over-temperature protection circuit is built-in in the G948 to prevent thermal overload. These power-saving features make the G948 ideal for use in a battery-powered application such as notebook computers, and portable devices.
These devices feature a shutdown function and are offered in active low with auto discharge. The G948 is specifically designed for ceramic output capacitors.
The G948 comes in a space-saving SOT-23-5, TSOT23-5, SC70-5 and TDFN2x2-6packages
Features
● VIN Range: 2.5V ~ 6V
● VOUT Range: 0.8V ~ 5.0V ±1% ( ±20mV )
● 3-Kind of SET Voltages: 0.8V, 1.0V, 1.2V ±1%
● Maximum IOUT Rated: 300mA
● Dropout Voltage: 210mV @ IOUT = 0.3A, VOUT = 3.3V
● 60μA No-Load Supply Current
● Stable with Ceramic Capacitors
● Output Discharge for Fast Turn-Off
● Over-Temperature Protection
● Short-Circuit Protection
Applications
● Notebook Computers
● Portable Devices
● Hand-Held Devices
