| 型號： | CJ6107A33G |
| 廠 商： | |
| 品牌/商標: | JSCJ/長晶科技 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
長晶科技 CJ6107A33G 高PSRR 1A CMOS穩壓器
INTRODUCTION
The CJ6107 Series are a group of positivevoltage regulators manufactured by CMOStechnology with high ripple rejection,ultra-fast transient response and lowdropout voltage, which provide large outputcurrents even when the difference of theinput-output voltage is small. Each of theCJ6107 series consists of a high-precisionvoltage reference, an error correction circuit,and a current limited output driver. Thus theseries are very suitable for thebattery-powered equipments, wirelesscommunication applications, industryequipments and so on.
Features
● Guaranteed Output Current：1.0A（Typ.）
● Low Quiescent Current：70μA（Typ.）
● Output Voltage Range：1.5V～5.0V
● Input Voltage Range：2.5V～6.0V
● High Accuracy：±2％（Typ.）
● Dropout Voltage：500mV@1.0A（3.0V Typ.）
● Excellent Line Regulation：0.02％/V
● High PSRR : 70dB@1KHz
● Built-in Current Limiter & ThermalProtection
● Short Circuit Current Fold-back
● Output Capacitor：Ceramic Compatible
Applications
● Battery powered systems
● Portable instrumentations
● GRS Receivers
● Wireless devices
