| 型號： | CJ6211B25M |
| 廠 商： | |
| 品牌/商標: | JSCJ/長晶科技 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
CJ6211B25M 江蘇長晶 低壓差穩壓器 具有低靜態電流
INTRODUCTION
The CJ6211 series are a group of positive voltage regulators manufactured by CMOS technologies with high ripple rejection, ultra low noise, low power consumption and low dropout voltage, which can prolong battery life in portable electronics. The CJ6211 series work with low-ESR ceramic capacitors, reducing the amount of board space necessary for power applications. The CJ6211 series consume less than 0.1μA in shutdown mode and have fast turn-on time less than 50μs.The series are very suitable for the battery-powered equipments, such as RF applicationsand other systems requiring a quiet voltage source.
Features
● High Ripple Rejection: 80dB@1kHz
● Low Dropout Voltage: 55mV@100mA
● Low Quiescent Current: 50μA
● Excellent Line and Load Transient Response
● Operating Voltage Range: 1.8V ~ 6.0V
● Output Voltage Range: 0.8V ~ 5.0V
● High Accuracy: ±2% (Typ.)
● Output Noise Voltage: 40 μVRMS (VOUT = 3.3V, 10Hz ~ 100kHz)
● Built-in Current Limiter, Short-Circuit Protection
● TTL- Logic-Controlled Shutdown Input
Applications
● Cellular and Smart Phones
● Laptop, Palmtops and PDA
● Digital Still and Video Cameras
● Portable Audio Video Equipments
● Radio control systems
● Battery-Powered Equipments
