| 型號： | CJ6300BM |
| 廠 商： | |
| 品牌/商標: | JSCJ/長晶科技 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
長晶 CJ6300BM 低壓差CMOS穩壓器 現貨熱銷
FEATURES
● 500mA RF Low-Dropout Regulator With Enable
● Ultralow-Noise：40μVRMS(10Hz~100kHz)
● High PSRR：70dB@1kHz
● Fast Start-Up Time (20μs)
● Excellent Load/Line Transient Response
● Low Dropout Voltage: 110mV@100mA
● Stable With a 1μF Ceramic Capacitor
● Available in Adjustable Voltage Version (0.6V to 5.5V)
● Built-in Current Limiter, Short-Circuit Protection
APPLICATIONS
● RF: VCOs, Receivers, ADCs
● Cellular and Cordless Telephones
● Handheld Organizers
● Audio
● Bluetooth, Wireless LAN
● Tablet, MID
