| 型號： | CJ6376B33M |
| 廠 商： | |
| 品牌/商標(biāo): | JSCJ/長晶科技 |
| 產(chǎn)品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
長晶CMOS穩(wěn)壓器 CJ6376B33M 深圳熱銷中
Features
● Input Voltage Range: 2.5V ~ 36V
● Fixed Output Voltage Available from 1.2V to 12V
● Output Voltage Tolerance:
- CJ6376 Series:
±2% for Conventional Device
±1% can be Customized
- CJ7500S Series: Available in ±2% and ±1% Grade
- CJ75L00S Series: Available in ±2% and ±1% Grade
● Output Current: up to 300mA
● Low Quiescent Current: 2.0μA (Typ.)
● Dropout Voltage: 300mV@100mA (VOUT = 3.3V)
● Low Output Noise: 27×VOUT μVRMS (10Hz ~ 100kHz)
● Power Supply Rejection Ratio: 70dB@1kHz
● Excellent Transient Response
● Integrated Fault Protection:
- Fold-back Current Limit
- Thermal Shutdown
- Short-circuit Protection
Applications
● Car Navigation Systems
● Cordless Phones
● LAN Cards
● Laptop, Palmtops and PDAs
● PC Peripherals with Memory
● Portable Audio Video Equipments
● Radio Control Systems
● Single-lens Reflex DSC
● Ultra Low Power Microcontrollers
● Wireless Communication Equipments
