| 型號： | CJ6386A33G |
| 廠 商： | |
| 品牌/商標: | JSCJ/長晶科技 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
CJ6386A33G JSCJ長晶 45V低壓差穩壓器
Features
● Low Quiescent Current: 2μA
● Operating Voltage Range: 2.5V ~ 45V
● Output Current: 250mA
● Low Dropout Voltage: 700mV@100mA(VOUT = 3.3V)
● Output Voltage: 2.1 ~ 5.0V
● High Accuracy: ±2%/±1%(Typ.)
● High Power Supply Rejection Ratio: 70dB@1kHz
● Low Output Noise: 27μVRMS (10Hz ~100kHz)
● Excellent Line and Load Transient Response
● Built-in Current Limiter, Short-Circuit Protection
● Over-Temperature Protection
● Stable with Ceramic or Tantalum Capacitor
Applications
● Cordless Phones
● Radio control systems
● Laptop, Palmtops and PDAs
● Single-lens reflex DSC
● PC peripherals with memory
● LAN Cards
● Ultra Low Power Microcontrollers
● Wireless Communication Equipments
● Portable Audio Video Equipments
● Car Navigation Systems
