代理長晶 CJ9340T6 高效1.2MHz升壓穩壓器
INTRODUCTION
The CJ9340T6 is a constant frequency, currentmode step-up converter intended for small, low power applications. The CJ9340T6 switches at 1.2MHz and allows the use of tiny, low cost capacitors and inductors 2mm or less in height. Internal soft-start results in small inrush current and extends battery life.
The CJ9340T6 includes under-voltage lockout, current limiting, and thermal overload protection to prevent damage in the event of an output overload. The CJ9340T6 is available in a small 6-pin SOT-23 package.
FEATURES
● 2V to 24V Input Voltage
● Up to 28V Output Voltage
● Integrated 80mΩ Power MOSFET
● 1.2MHz Fixed Switching Frequency
● Internal 4A Switch Current Limit
● Internal Compensation
● Thermal Shutdown
● Output Adjustable from 0.6V
● Available in a 6-pin SOT-23 package
APPLICATIONS
● Digital Set-top Box (STB)
● Tablet Personal Computer (Pad)
● LCD Bias Supply
● Battery-Powered Equipment
● Portable Media Player (PMP)
● General Purposes
