CJ9482E8 江蘇長晶 單片降壓開關穩壓器 ESOP8封裝

CJ9482E8 江蘇長晶 單片降壓開關穩壓器 ESOP8封裝
型號: CJ9482E8
廠 商:
品牌/商標: JSCJ/長晶科技
產品類別: 集成電路/IC- DC/DC電源芯片
聯系人: 顏先生/William
電話: 0755-82170220,21001680


產品詳情

CJ9482E8 江蘇長晶 單片降壓開關穩壓器 ESOP8封裝


INTRODUCTION

CJ9482 is a monolithic 36V,3.1A step-down switching converter. CJ9482 integrates a 36V 79mΩ high side and a 36V, 62mΩ low side MOSFETs to provide 3.1A continnuous load current over a 6.5V to 36V wide operating input voltage with 33V input over voltage protection. Peak current mode control provides fast transient responses and cycle-bycycle current limiting. Programmable softstart prevents inrush current at power.


FEATURES

● Wide Input Range:6.5V-36V

● With input Over Voltage Protection

● 3.1A continuous Output Current

● Programmable Soft-Start limits the inrush current at tur-on mode

● High Efficiency: Up to 95% at Light Load

● Stable with Low ESR Ceramic Output Capacitors

● Fixed 300KHz Switching Frequency

● Input Under-Voltage Lockout

● Output Over-Voltage Protection

● 0.9V Reference for Low Output voltages

● Output short protection

● Thermal shutdown

● Available in ESOP8 Package


APPLICATIONS

● Televisions

● USB car charger

● Distributed Power Systemsems

● DVD,LCD TVS

● Set-Top-Box

● OLPC,Netbook

● Datacom,XDSL modemsdems

● Portable charging devicece
