1.產品簡介

IT6563

Single Chip 4 Lane DisplayPort1.2 to HDMI2.0 Converter with

Embedded MCU

VL103+IT6563：Type-C轉HDMI 科瑞芯公司熱銷！

2. Features

2.1 DisplayPort Receiver

Compliance with DisplayPort Specification V1.2a at 1.62/2.7/5.4 Gbps data rate (Low bit

rate/High bit rate/High bit rate 2)

Support flexible 1/2/4 lanes configurations; Full 21.6Gbps data rate support (4 lanes at

5.4Gbps)

Support DPCD Rev.1.2

Support metadata transport for static High Dynamic Range (HDR)

Support HDCP 1.3/2.2 with HDCP key embedded

Support MCCS over AUX

Support 3D display left/right field/frame

Support Spread Spectrum Clocking up to 0.5% down-spread to reduce EMI

Bi-direction Color Space Conversion (CSC) between RGB and YCbCr color spaces with

programmable coefficients.

Support 8-channel, uncompressed LPCM I2S audio with sample rates of 32~192 kHz and

sample sizes of 16~24 bits, and HBR audio.

Automatic loss of signal detection for Link management

Intelligent, programmable power management

Embedded two blocks EDID RAM to saving BOM cost

Compliance with “DP only” or “DP++” source device
